FT8-V5

FT8-V5

Finger touch portable interactive whiteboard can turn any projection area to be the multi touch system (interactive board), such as a wall, floor, fabric screen, ordinary white(green)board, table, TV set, LCD screen and so on. Using Oway device, you can fully control your computer and any software on board by the finger or IR pen to make accurate writing and annotating.

Many applicable scenarios

Many applicable scenarios

The product has many application scenarios. It can realize touch writing and play games on any surface, and can be used in large amusement parks, classrooms, meeting rooms, etc.

Easy to install

Easy to install

The product only needs to be connected to the computer、projector and the sensor, and the positioning is automatically completed. The installation is very convenient. The whole process only takes about 2 minutes.

High level of accuracy

High level of accuracy

After continuous development and testing of the product, the product can reach 17ms instant response, so that you will not feel any delay in the process of writing, and the 720p HD lens can further enhance the accuracy of the sensor, giving you the feeling of writing on paper.

Multi users (support 255 points)

Multi users (support 255 points)

Supports simultaneous use of 100 touch points, all software that supports windows native multi-touch support multiple points, for example, one finger writes and two fingers zoom in/out, multiple users are allowed to write at the same time.

Basic Info.

FT8-V5
Calibration Automatic(5 seconds) / Manual (4/15 points)
Multi-touch 100 points touch,writing and erasing can be performed simultaneously
Latency <6 ms
Filter Software auto-control、Enhance stability
Min Active Size 30 inches
Max Active Size Pen touch:220inches、Finger touch:150inches、Throwball game:400inches(no sunshine room)
Technology Laser image calibration technology
Positional Accuracy ±1 pixel (resolution: 4096*4096)
Aspect Ratio 4:3/16:9/16:10
Projector Ratio Ultra short throw:0.28/0.16 Installation distance:about 0.4 - 1m
Short throw(Middle throw):0.83 /0.57/0.38 Installation distance:about 1 - 3m
Long throw:1.28 Installation distance:about 3 - 5m
Sensor Power 5 W
Laser Emitter Power 280mW * 2
Sensor Voltage/Current 5V/500MA
Laser Emitter Voltage/Current 3.3V/2A
Infrared Coverage Area 6*8 m
Signal Refresh Rate 60/180fps
Connect The sensor and computer are connected by USB cable,laser emitter just need power
Laser Emitter Weight 146 g
Sensor Weight 67 g
OS Requirement Windows xp/vista/7/8/10/11
Software OwayIWB、Multi-Board
Certification CE、FCC、RoHS
Warranty Sensor(3 years)、Laser emitter(1 year)、IR pen(1 year)
Package 1.Sensor、2.Emitter、3.IR pen、4.USB cable(10m)、5.Remote、6.Power adaptor、7.CD with software
