WB2800

WB2800

Pen touch portable interactive whiteboard can turn any projection area to be the multi touch system (interactive board), such as a wall, floor, fabric screen, ordinary white(green) board, table, TV set, LCD screen and so on. Using Oway device, you can fully control your computer and and any software on board by the IR pen or finger to make accurate writing and annotating.

Good quality and easy to install

Good quality and easy to install

We have a warranty of up to 3 years to ensure the customer’s experience. The sensor’s lens rotation angle can reach 180 degrees, and you can install it on ceilings, tables, projectors and other venues, just use the data cable to connect the projector, sensor and computer, all interactive experience begins.

Multi users (maximum support 100 points)

Multi users (maximum support 100 points)

Support all native windows multi points software, such as using one pen to write, two pens to zoom out and zoom in a picture.support multi users to write at the same time, and will not interfere with each other,and the game also supports multi people to play at the same time.

Supports adjustable screen size, up to 300 inches

Supports adjustable screen size, up to 300 inches

This is an adjustable large screen that integrates writing, creation, teaching, and conferences. Its portable camera sensor unit converts any flat surface (such as a projection wall or LED screen) into a mature multi-touch display.

Strong anti-interference ability

Strong anti-interference ability

There are no special requirements for the installation environment. It has its own anti-interference ability, which can automatically eliminate relevant unfavorable factors, so that it can achieve the best use effect without human interference.

Precision craftsmanship metal frame

Precision craftsmanship metal frame

The outer frame adopts one-piece molding technology. After more than 16 processes, the alloy plate becomes an exquisite outer frame, which can give you a different visual effect in terms of appearance and feeling.

Applicable to various distances

Applicable to various distances

We provide interactive sensors with various throw ratios, which can be used at different distances, and also we can provide matching solutions for different projection sizes. Different throw ratios and the distance from the projection screen are TR0.16 : 0.4~0.7m、 TR0.28: 0.7~1m、TR0.38: 1~1.5m、TR0.57: 1.5~2m、TR0.83: 2~3m、TR1.28: 3~5m, you can consult our customer service to match according to your environment.

Basic Info.

Signal Receiver
Movement Detection Infrared
Active Area(Max projection size) 300 inches
Active Area(Horizontal angle) 33° +/- 2°
Active Area(Vertical angle) 0° - 30°
Throw Ratio 0.16、0.28、0.38、0.57、0.83、1.28
Calibration Technology Infrared calibrationing
Active Distance(From projection screen) 0.3 - 5 m
Connectivity Interface 1 * USB cable(connection distance up to 20 m)
Power Requirement 5 W(from USB port)
Size L*W*H:85*50*57 mm
Power Consumption 5 W
Color Silver
Weight 135 g
IR Pointer
Movement Detection Technology Led light
Power Requirement AAA * 2
Trigger Methods of Pointer Button
Pen Body Weight 87g(with battery)
Pointer Extendable Length 417 - 608mm(length)、8 - 15mm(diameter)
Net Weight 68 g
IR Pen
Movement Detection Technology Led light
Power Requirement AAA * 2
Pen Body Dimension 163mm(length)、8 - 14mm(diameter)
Pen Weight 60g(with battery)
Net Weight 37 g
System Requirements
OS Required Windows xp/vista/7/8/10/11、Ubuntu、Debain、Mac os
Processor Type AI high-speed processor
RAM Size 128 MB
Min Hard Drive Space 30 MB
Customize Interactive IDM interactive wall factory electronic whiteboard interactive touch wall Interactive Pens For Projector Interactive Factory Price From Oway Interactive Whiteboards
